Patriot Air Shock
The most advanced heavy duty air shocks on the market, engineered for ATVs to Super Duties
World's Most Advanced Air Shock
The Patriot Air Shock is a patent-pending design that redefines what air shocks can do. Our technology gives you the ability to adjust ride height, vehicle spring progression, and dynamic dampening — all in a single unit.
The 7075-T6 high-performance 4″ dampening piston flows more than any other dampening piston on the planet. Combined with a nitride-coated tube, fine-ground hard chrome, and stroke beyond 22″, these shocks outperform anything else in the world.
One Shock. Every Application.
The air spring can be tuned to act like a coil spring with a linear-to-flat force curve for high-performance off-road capability. Tune it to act like a leaf spring with high progression for towing. Or dial in infinite settings in between.
The internal hydraulic tunable bump stop lets you fine-tune the system for your exact driving conditions. Combine adjustable ride height with a 5,000-pound load capacity and you get a ride like no other.
From ATVs to Super Duties
One platform engineered for every vehicle class. These air shocks turn any ride into an all-around performance vehicle.
Built Without Compromise
How the Patriot Air Shock Works
Traditional coilover shocks use a fixed-rate spring to support the vehicle's weight. Leaf springs use stacked steel leaves with a progressive rate. Both are compromises — tuned for one scenario and merely adequate at everything else. The Patriot Air Shock eliminates that trade-off.
By replacing the mechanical spring with a sealed, pressurized air chamber, you gain the ability to change the effective spring rate on demand. Increase pressure for heavy loads or towing. Decrease it for a plush highway ride. The air spring can be tuned to mimic a linear coil spring curve for responsive off-road handling or a progressive leaf spring curve for load-carrying stability — or anything in between.
The integrated hydraulic dampening system uses a 4-inch billet aluminum piston that flows more oil than any other dampening piston available. This means better heat dissipation, more consistent damping across long descents or washboard terrain, and a smoother ride under every condition. The internal hydraulic bump stop adds a final layer of tunability, preventing harsh bottom-outs without sacrificing travel.
Air Shock vs. Traditional Suspension
Why builders are choosing the Patriot Air Shock over conventional coilovers and leaf springs for their classic 4x4 restomods.
| Feature | Patriot Air Shock | Coilover | Leaf Spring |
|---|---|---|---|
| Adjustable Spring Rate | Infinite | Fixed | Fixed |
| Ride Height Adjustable | Yes | Limited | No |
| Load Capacity (per corner) | 5,000 lbs | 500-1,500 lbs | 2,000-4,000 lbs |
| Usable Stroke | 22″+ | 8-14″ | 4-6″ |
| Load Leveling | Built-in | No | No |
| Towing Capability | Excellent | Poor | Good |
| Off-Road Articulation | Full Travel | Good | Limited |
Upgrade Your Ride
Contact us for air shock pricing, fitment information, and custom applications.
